> Products > Absolute Depth Filter |
|
|
|
 |
Description |
| •
|
IA (IXTUS Absolute)
filters are absolute- |
| • |
IA is good for CMP(Chemical
Mechanical Polishing) process because of absolute
grade, It is constructed of olefin fiber to
ensure high efficiency the multi-layer. |
| • |
IA is used for the
filtration of both oxide and metal slurries
at chemical mechanical polishing process.
|
| • |
This multi-layer
depth structure provides high dirt holding
capacity. |
| • |
Available in a wide
absolute filter removal ratings from 0.5§
to 5§ |
| • |
IA (IXTUS Absolute)
filters are absolute-rated depth filters with
Polyolefine material. |
|
|
|
Advantage in use |
| •
|
Excellent compatibility
with most chemical solutions. |
| • |
Enhanced particle
removal in aqueous fluids. |
| • |
Low extractables
and media migration. |
| • |
High quality cleanness
in process line. |
| • |
There are no releasing
particle during variations in flow or pressure. |
|
 |
|
|
Specification |
Material of
Construction |
Recommended
Operating conditions |
Removal Ratings |
Cartridge
Dimensions |
Removal
Efficiency |
Media
:
Polypropylene
microfiber 100%
Core/cage :
Polypropylene
Sealing :
Thermal bonding |
Maximum
Differential
Pressure :
70psi(4.8bar) at 25¡É |
Grade |
Ratings
(§) |
In diameter
: 30§®
Out diameter
: 65§® |
Absolute grade
(99.98%) |
| D5 |
0.5 |
| 01 |
1 |
| 03 |
3 |
| 05 |
5 |
| * Please inquire concerning non-standard
size. |
|
Application |
| • |
Oxide slurry, Metal slurry,
Chemical slurry, Pigment, Ink jet |
|
|
|
