Description |
| •
|
IPH pleated filter
cartridges offer superior dirty holding capacity
and high removal efficiency compared to conventional
pleated cartridges due to their multiple layered
construction. |
| • |
IPP pleated filter
cartridges offer superior removal efficiency
compared to conventional pleated cartridges
due to their multiple layered construction.
|
| • |
IPC pleated filter
cartridges also provides a long life cycle. |
| • |
Pleated cartridges
are available in a wide selection of micron
rating to meet clients¡¯ filtration requirement. |
| • |
All polypropylene
components and thermal bonded manufacturing
enable the smallest contaminant extraction
and higher durability. |
| • |
No adhesive minimizes
contamination from media extraction |
|
|
|
Advantage in use |
| • |
Long life cycle &
a large surface area. |
| • |
Reduced product waste. |
| • |
Reduced cartridge change
out frequently. |
| • |
Increased productivity
& plant capacity. |
|
|
Specification |
| Material of
Construction |
Recommended
Operating conditions |
Removal Ratings(§) |
Cartridge
Dimensions |
Media
:
Polypropylene
Support and drainage
:
Polypropylene
Core/cage/end-caps
:
Polypropylene
Sealing :
Thermal bonding |
Maximum
Differential
Pressure :
75psi(5.1bar) at 25¡É
25psi(1.7bar) at 80¡É |
IPH |
IPP |
IPC |
Out diameter
:
69§®
Length(§®) :
250, 254, 500, 508, 750,762, 1000, 1016 |
| 0.2 |
10 |
0.2 |
6 |
0.3 |
30 |
| 0.45 |
30 |
0.45 |
10 |
0.6 |
50 |
| 0.6 |
|
0.6 |
20 |
1.2 |
|
| 1.2 |
|
1.2 |
40 |
2.5 |
|
| 2.5 |
|
2.5 |
70 |
5 |
|
| 5 |
|
4.5 |
|
10 |
|
| * Please inquire concerning non-standard
size. |
|
Application |
| • |
Electronic : LCD, PDP,
EL, Rinse solution, Fine chemical. |
| • |
Prefiltration, DI-water,
Solvents,. Selected acids & Bases, Chemicals. |
|
|
|
